Linux Complete Capstone: Linux Admin Labs to Build, Secure, Monitor and Fix a Production Server

By Ravindra Bagale, trainer · LinkedIn · Last updated: 26 October 2026

1. An everyday example: opening a new clinic

Why do we need this?

Dr. Kulkarni opens a small clinic in Kothrud. First the place is built: rooms, power, furniture, the reception computer. Then it is secured: locks, a CCTV camera, a cupboard for medicines with a key. Then it is monitored: a register at reception, a fridge thermometer for vaccines, a daily check. Patient files are photocopied every evening and kept at home. And when something breaks, a fuse, a leaking tap, the staff know whom to call and what to check first.

What is it?

Building the clinic = install, users, storage, packages and the app. Locks and CCTV = SSH keys, firewall, SELinux and auditd. Register and thermometer = metrics, logs and alerts. Evening photocopies = backups. Knowing whom to call = runbooks and break-fix skills.

How to do it (step by step)

2. Capstone brief and the build plan

Why do we need this?

Real admins never start typing commands straight away. A one-page plan avoids rework and makes the server repeatable.

What is it?

The brief: Shree Traders, a Pune distributor, needs an internal orders web app. Requirements: Rocky Linux 9 VM with 2 vCPU, 4 GB RAM, a 20 GB OS disk and a 10 GB data disk; nginx in front of a small Python app on port 8000; data on LVM at /srv/app; only SSH key logins; firewall open for 22 (office subnet only), 80 and 443; daily backups kept 14 days; alerts when disk passes 80 percent or the app health check fails. Write this plan first and keep it in /root/PLAN.md.

How to do it (step by step)

1. Record the server facts at the start.

hostnamectl | egrep 'Static|Operating|Kernel'; nproc; free -h | awk '/Mem/{print $2}'; lsblk -dno NAME,SIZE

Output:

   Static hostname: localhost
  Operating System: Rocky Linux 9.4 (Blue Onyx)
            Kernel: Linux 5.14.0-427.el9.x86_64
2
3.6Gi
vda 20G
vdb 10G

What it means: Matches the plan: 2 CPUs, about 4 GB, and the extra 10 GB disk vdb.

2. Set hostname, time zone and time sync.

sudo hostnamectl set-hostname orders01.shree.local; sudo timedatectl set-timezone Asia/Kolkata; sudo systemctl enable --now chronyd; chronyc tracking | grep -E 'Reference|System time'

Output:

Reference ID    : A29FC801 (time.cloudflare.com)
System time     : 0.000012 seconds fast of NTP time

What it means: Correct time matters for logs, TLS and backups.

3. Patch fully before anything else and reboot into the new kernel.

sudo dnf -y upgrade >/dev/null; sudo needs-restarting -r; echo rc=$?

Output:

Core libraries or services have been updated since boot-up:
  * kernel
Reboot is required to fully utilize these updates.
rc=1

What it means: rc=1 means reboot needed; reboot now while the server is not yet live.

3. Build: users, sudo and storage

Why do we need this?

Shared root logins and data on the OS disk are the two most common causes of messy, unsafe servers.

What is it?

Create named admin accounts in an admins group with sudo, a locked service account app that owns the application, and put application data on its own LVM volume so it can grow and be backed up separately. Use XFS, mount by UUID and verify with mount -a before rebooting.

How to do it (step by step)

1. Create admins and the service account.

sudo groupadd admins; sudo useradd -m -G admins ravi; sudo useradd -m -G admins asha; sudo useradd -r -m -d /srv/app -s /sbin/nologin app; echo '%admins ALL=(ALL) ALL' | sudo tee /etc/sudoers.d/admins; sudo visudo -cf /etc/sudoers.d/admins

Output:

%admins ALL=(ALL) ALL
/etc/sudoers.d/admins: parsed OK

What it means: Named people, a group rule, and a service user that cannot log in.

2. Create LVM on the data disk.

sudo pvcreate /dev/vdb; sudo vgcreate vg_data /dev/vdb; sudo lvcreate -n lv_app -L 6G vg_data; sudo mkfs.xfs -q /dev/vg_data/lv_app; sudo lvs vg_data

Output:

  Physical volume "/dev/vdb" successfully created.
  Volume group "vg_data" successfully created
  Logical volume "lv_app" created.
  LV     VG      Attr       LSize
  lv_app vg_data -wi-a----- 6.00g

What it means: 4 GB is left free in the VG to grow later.

3. Mount it persistently and fix ownership and SELinux label.

u=$(sudo blkid -s UUID -o value /dev/vg_data/lv_app); echo "UUID=$u /srv/app xfs defaults,nodev,nosuid 0 0" | sudo tee -a /etc/fstab; sudo mount -a; sudo chown app:app /srv/app; sudo restorecon -Rv /srv/app; findmnt /srv/app

Output:

UUID=8c2e... /srv/app xfs defaults,nodev,nosuid 0 0
TARGET   SOURCE                       FSTYPE OPTIONS
/srv/app /dev/mapper/vg_data-lv_app xfs    rw,nosuid,nodev,relatime

What it means: nodev and nosuid add safety on a data mount.

4. Build: deploy the app with systemd and nginx

Why do we need this?

Running an app by hand in a terminal dies when you log out and does not restart after a crash or reboot.

What is it?

Install Python and nginx, put the app in /srv/app, run it as a systemd service under the app user on 127.0.0.1:8000 with Restart=on-failure and basic hardening, and put nginx in front on port 80. SELinux needs the httpd_can_network_connect boolean so nginx can proxy.

How to do it (step by step)

1. Install packages and a tiny app.

sudo dnf -y install nginx python3 >/dev/null; sudo -u app tee /srv/app/app.py >/dev/null <<'PY'
from http.server import BaseHTTPRequestHandler, HTTPServer
class H(BaseHTTPRequestHandler):
    def do_GET(self):
        body = b'ok' if self.path == '/health' else b'Shree Traders orders'
        self.send_response(200); self.end_headers(); self.wfile.write(body)
HTTPServer(('127.0.0.1', 8000), H).serve_forever()
PY
ls -l /srv/app/app.py

Output:

-rw-r--r--. 1 app app 297 Oct 26 11:20 /srv/app/app.py

What it means: A stand-in app with a /health endpoint for monitoring.

2. Create the systemd unit with hardening.

sudo tee /etc/systemd/system/orders.service >/dev/null <<'U'
[Unit]
Description=Shree orders app
After=network-online.target
[Service]
User=app
WorkingDirectory=/srv/app
ExecStart=/usr/bin/python3 /srv/app/app.py
Restart=on-failure
RestartSec=3
NoNewPrivileges=yes
ProtectSystem=strict
ReadWritePaths=/srv/app
PrivateTmp=yes
[Install]
WantedBy=multi-user.target
U
sudo systemctl daemon-reload; sudo systemctl enable --now orders; curl -s 127.0.0.1:8000/health

Output:

ok

What it means: The app now starts at boot, restarts on crash and cannot write outside /srv/app.

3. Put nginx in front.

sudo tee /etc/nginx/conf.d/orders.conf >/dev/null <<'N'
server { listen 80; server_name orders01.shree.local;
  location / { proxy_pass http://127.0.0.1:8000; proxy_set_header Host $host; } }
N
sudo setsebool -P httpd_can_network_connect on; sudo nginx -t && sudo systemctl enable --now nginx; curl -s localhost/

Output:

nginx: the configuration file /etc/nginx/nginx.conf syntax is ok
nginx: configuration file /etc/nginx/nginx.conf test is successful
Shree Traders orders

What it means: nginx -t before reload, and the boolean is persistent with -P.

5. Secure: SSH, firewall and SELinux

Why do we need this?

A public server gets SSH password-guessing attempts within minutes of going online.

What is it?

Use SSH keys only, disable root login and passwords, allow only the admins group, and test from a second session before closing the first. Open only 22 for the office subnet and 80/443 for everyone with firewalld rich rules. Keep SELinux enforcing and check for denials.

How to do it (step by step)

1. Harden sshd with a drop-in file.

sudo tee /etc/ssh/sshd_config.d/10-hardening.conf >/dev/null <<'S'
PermitRootLogin no
PasswordAuthentication no
KbdInteractiveAuthentication no
AllowGroups admins
MaxAuthTries 3
S
sudo sshd -t && sudo systemctl reload sshd; sudo sshd -T | egrep 'permitrootlogin|passwordauthentication|allowgroups'

Output:

permitrootlogin no
passwordauthentication no
allowgroups admins

What it means: sshd -t first; keep your current session open while testing a new one.

2. Restrict SSH to the office subnet and open web ports.

sudo firewall-cmd --permanent --remove-service=ssh; sudo firewall-cmd --permanent --add-rich-rule='rule family=ipv4 source address=10.20.0.0/24 service name=ssh accept'; sudo firewall-cmd --permanent --add-service={http,https}; sudo firewall-cmd --reload; sudo firewall-cmd --list-all | egrep 'services|rule'

Output:

  services: cockpit dhcpv6-client http https
	rule family="ipv4" source address="10.20.0.0/24" service name="ssh" accept

What it means: Add the rich rule before removing ssh in real life so you never lock yourself out.

3. Confirm SELinux and look for denials.

getenforce; sudo ausearch -m AVC -ts today 2>&1 | tail -1; sudo dnf -y remove cockpit-ws >/dev/null; sudo firewall-cmd --permanent --remove-service=cockpit; sudo firewall-cmd --reload

Output:

Enforcing
<no matches>
success
success

What it means: No denials, and the unused cockpit service is removed to shrink the attack surface.

6. Secure: updates, fail2ban, auditing and TLS

Why do we need this?

Most real breaches use known, already-patched bugs, and without an audit trail you cannot even tell what happened.

What is it?

Turn on automatic security updates with dnf-automatic, add fail2ban for SSH, add auditd rules for sudoers and SSH config changes, and enable HTTPS. For an internal name use a company CA or a self-signed certificate for the lab; for a public name use Let's Encrypt with certbot.

How to do it (step by step)

1. Automatic security updates.

sudo dnf -y install dnf-automatic >/dev/null; sudo sed -i 's/^upgrade_type.*/upgrade_type = security/; s/^apply_updates.*/apply_updates = yes/' /etc/dnf/automatic.conf; sudo systemctl enable --now dnf-automatic.timer; systemctl list-timers dnf-automatic.timer --no-pager | sed -n 2p

Output:

Tue 2026-10-27 06:12:41 IST 18h left - - dnf-automatic.timer dnf-automatic.service

What it means: Security patches apply daily; kernels still need a planned reboot.

2. fail2ban and audit rules.

sudo dnf -y install epel-release >/dev/null && sudo dnf -y install fail2ban >/dev/null; printf '[sshd]\nenabled = true\nmaxretry = 4\nbantime = 1h\n' | sudo tee /etc/fail2ban/jail.d/sshd.local >/dev/null; sudo systemctl enable --now fail2ban; printf -- '-w /etc/sudoers -p wa -k priv\n-w /etc/sudoers.d/ -p wa -k priv\n-w /etc/ssh/sshd_config.d/ -p wa -k sshcfg\n' | sudo tee /etc/audit/rules.d/50-admin.rules >/dev/null; sudo augenrules --load >/dev/null; sudo auditctl -l | wc -l

Output:

3

What it means: Three watches loaded; any edit to sudo or SSH config is now recorded with the user's login id.

3. Enable HTTPS with a lab certificate.

sudo openssl req -x509 -newkey rsa:2048 -nodes -days 365 -subj '/CN=orders01.shree.local' -keyout /etc/pki/tls/private/orders.key -out /etc/pki/tls/certs/orders.crt 2>/dev/null; sudo tee -a /etc/nginx/conf.d/orders.conf >/dev/null <<'N'
server { listen 443 ssl; server_name orders01.shree.local;
  ssl_certificate /etc/pki/tls/certs/orders.crt; ssl_certificate_key /etc/pki/tls/private/orders.key;
  location / { proxy_pass http://127.0.0.1:8000; } }
N
sudo nginx -t 2>&1 | tail -1; sudo systemctl reload nginx; curl -sk https://localhost/health

Output:

nginx: configuration file /etc/nginx/nginx.conf test is successful
ok

What it means: For production use a real CA; the steps in nginx stay the same.

7. Monitor: metrics, logs, health checks and alerts

Why do we need this?

Users should never be the first to tell you the site is down or the disk is full.

What is it?

Expose metrics with node_exporter for Prometheus, keep the journal persistent and size-limited, rotate app logs, and add a small systemd timer that checks the health URL and disk usage every minute and sends an alert (here to a webhook) when a threshold is crossed. Test the alert by actually breaking something.

How to do it (step by step)

1. Persistent, size-limited journal.

sudo mkdir -p /etc/systemd/journald.conf.d; printf '[Journal]\nStorage=persistent\nSystemMaxUse=500M\n' | sudo tee /etc/systemd/journald.conf.d/size.conf >/dev/null; sudo systemctl restart systemd-journald; journalctl --disk-usage

Output:

Archived and active journals take up 24.0M in the file system.

What it means: Logs survive reboots and cannot fill the disk.

2. A health check script and timer.

sudo tee /usr/local/bin/healthcheck >/dev/null <<'H'
#!/usr/bin/env bash
set -uo pipefail
msg=''
curl -fsS -m 5 http://127.0.0.1/health >/dev/null || msg+='app health failed; '
use=$(df --output=pcent /srv/app | tail -1 | tr -dc 0-9)
(( use >= 80 )) && msg+="disk /srv/app ${use}%; "
if [[ -n $msg ]]; then logger -t healthcheck "ALERT $msg"; curl -fsS -m 5 -d "text=orders01: $msg" "${ALERT_URL:-http://10.20.0.5/hook}" >/dev/null || true; fi
H
sudo chmod 755 /usr/local/bin/healthcheck
printf '[Unit]\nDescription=health\n[Service]\nType=oneshot\nExecStart=/usr/local/bin/healthcheck\n' | sudo tee /etc/systemd/system/healthcheck.service >/dev/null
printf '[Unit]\nDescription=health every minute\n[Timer]\nOnCalendar=minutely\n[Install]\nWantedBy=timers.target\n' | sudo tee /etc/systemd/system/healthcheck.timer >/dev/null
sudo systemctl daemon-reload; sudo systemctl enable --now healthcheck.timer; systemctl is-active healthcheck.timer

Output:

active

What it means: Every minute it checks the app and the disk and alerts only on problems.

3. Test the alert by stopping the app.

sudo systemctl stop orders; sleep 65; journalctl -t healthcheck -n 1 --no-pager -o cat; sudo systemctl start orders

Output:

ALERT app health failed;

What it means: The alert fired. An alert you have never seen fire is an alert you cannot trust.

8. Backup and restore

Why do we need this?

A backup that has never been restored is only a hope. Disks fail, people delete things, and ransomware encrypts data.

What is it?

Back up /srv/app, /etc and a list of installed packages with restic to a separate backup host over SFTP, encrypted. Run it nightly with a systemd timer, keep 14 daily and 4 weekly snapshots, and restore to a temporary folder every month to prove it works. Follow 3-2-1: three copies, two kinds of media, one off site.

How to do it (step by step)

1. Initialise the repository.

sudo dnf -y install restic >/dev/null; export RESTIC_REPOSITORY=sftp:backup@10.20.0.9:/backups/orders01 RESTIC_PASSWORD_FILE=/root/.restic-pass; sudo -E restic init | tail -1

Output:

created restic repository 3f9a1c22be at sftp:backup@10.20.0.9:/backups/orders01

What it means: Keep the password file safe and a copy offline; without it the backup is useless.

2. Run a backup and apply retention.

rpm -qa | sort | sudo tee /root/pkglist.txt >/dev/null; sudo -E restic backup /srv/app /etc /root/pkglist.txt --tag nightly -q; sudo -E restic forget --keep-daily 14 --keep-weekly 4 --prune -q; sudo -E restic snapshots --compact | tail -2

Output:

3c1d7e2a  2026-10-26 11:48:03  orders01  nightly  /etc, /root/pkglist.txt, /srv/app
1 snapshots

What it means: Then wrap these lines in a script with a nightly systemd timer.

3. Prove a restore.

sudo -E restic restore latest --target /tmp/restore --include /srv/app/app.py -q; diff /srv/app/app.py /tmp/restore/srv/app/app.py && echo restore-ok

Output:

restore-ok

What it means: Identical file restored. Write the date in the runbook each time you test.

9. Fix: six production break-and-fix scenarios

Why do we need this?

Interviewers and on-call shifts both test whether you can find the cause quickly and safely, not whether you remember every flag.

What is it?

Ask a partner to break your server with the commands below while you look away, then fix it using the method: symptom, scope, recent changes, logs, resources, fix, verify, write down. Each scenario shows the break, the clue and the fix.

How to do it (step by step)

1. Scenario 1 and 2: 502 Bad Gateway.

curl -sI localhost | head -1; systemctl is-active orders; getsebool httpd_can_network_connect; sudo tail -1 /var/log/nginx/error.log

Output:

HTTP/1.1 502 Bad Gateway
active
httpd_can_network_connect --> off
... connect() to 127.0.0.1:8000 failed (13: Permission denied) while connecting to upstream

What it means: App is up, but permission denied plus the boolean off points to SELinux. Fix: setsebool -P httpd_can_network_connect on. If the app were inactive, check journalctl -u orders and start it.

2. Scenario 3: disk full.

df -h /srv/app | tail -1; sudo du -xah /srv/app | sort -h | tail -2; sudo lsof +L1 | tail -1

Output:

/dev/mapper/vg_data-lv_app  6.0G  6.0G   20K 100% /srv/app
5.7G	/srv/app/debug.log
6.0G	/srv/app

What it means: Truncate instead of deleting if a process holds it: sudo truncate -s 0 /srv/app/debug.log. Then add logrotate, or grow: lvextend -r -L +2G /dev/vg_data/lv_app.

3. Scenarios 4, 5 and 6: SSH, emergency mode and high load.

sudo firewall-cmd --list-rich-rules | wc -l; findmnt --verify 2>&1 | tail -1; ps -eo pid,user,%cpu,cmd --sort=-%cpu | head -2

Output:

0
   1 parse errors, 0 errors, 0 warnings
    PID USER  %CPU CMD
   4121 app   99.3 python3 -c while True: pass

What it means: No rich rule: re-add it from the console. fstab parse error: fix the line from the emergency shell after mount -o remount,rw /. Runaway process: confirm with the owner, then kill 4121 and find why it started.

10. Runbook, handover and final checklist

Why do we need this?

A server only one person understands is a risk. A runbook lets anyone on the team handle it at 2 a.m.

What is it?

Write /root/RUNBOOK.md with: what the server does, how to reach it, services and ports, where data and logs live, how to deploy, how to restore, the six scenarios and their fixes, and who to call. Then run a final checklist script that checks every requirement from the plan and prints PASS or FAIL.

How to do it (step by step)

1. A final checklist script.

cat > check.sh <<'C'
#!/usr/bin/env bash
ok(){ printf '%-28s %s\n' "$1" "$( eval "$2" >/dev/null 2>&1 && echo PASS || echo FAIL)"; }
ok 'SELinux enforcing' '[[ $(getenforce) == Enforcing ]]'
ok 'root ssh disabled' 'sshd -T | grep -q "permitrootlogin no"'
ok 'password ssh disabled' 'sshd -T | grep -q "passwordauthentication no"'
ok 'app healthy' 'curl -fs localhost/health'
ok 'https healthy' 'curl -fsk https://localhost/health'
ok 'data mounted' 'findmnt /srv/app'
ok 'backup timer' 'systemctl is-active restic-backup.timer'
ok 'health timer' 'systemctl is-active healthcheck.timer'
ok 'auto updates' 'systemctl is-active dnf-automatic.timer'
ok 'no failed units' '[[ -z $(systemctl --failed --no-legend) ]]'
C
sudo bash check.sh

Output:

SELinux enforcing            PASS
root ssh disabled            PASS
password ssh disabled        PASS
app healthy                  PASS
https healthy                PASS
data mounted                 PASS
backup timer                 PASS
health timer                 PASS
auto updates                 PASS
no failed units              PASS

What it means: Every line maps back to a requirement in PLAN.md.

2. Reboot and run it again.

sudo systemctl reboot
# after login
sudo bash check.sh | grep -c PASS

Output:

10

What it means: The real proof: everything comes back on its own after a reboot.

3. Write the handover note.

cat /root/HANDOVER.txt

Output:

orders01.shree.local (10.20.0.21), Rocky 9.4. nginx :80/:443 -> orders.service :8000 (user app). Data /srv/app on vg_data/lv_app (6G, 4G free). SSH keys only, admins group, office subnet. Backups restic nightly 01:30 to 10.20.0.9, last restore test 2026-10-26 OK. Alerts via healthcheck.timer. Runbook /root/RUNBOOK.md.

What it means: Five lines a new teammate can act on immediately.

11. Real examples from many industries

Why do we need this?

The same Linux skill shows up in every kind of company. Seeing it in many places helps you remember it.

What is it?

Each row is a made-up team. It shows who uses this and how.

How to do it (step by step)

12. Common errors and how to fix them

Why do we need this?

Everyone hits these errors. Knowing the cause saves hours.

What is it?

Read the exact message first. Then match it to a row below.

How to do it (step by step)

13. Troubleshooting step by step

Why do we need this?

When the production server misbehaves, follow the same order every time and write down what you find.

What is it?

Go top to bottom. Stop at the first step that shows the problem.

How to do it (step by step)

1. Is it up and reachable?

curl -sI https://orders01.shree.local -k | head -1

2. Which service is unhappy?

systemctl --failed; systemctl status orders nginx --no-pager | grep Active

3. What do the logs say?

journalctl -p err -b --no-pager | tail -20

4. Resources: CPU, memory, disk.

uptime; free -h; df -h

5. Security layers: SELinux and firewall.

ausearch -m AVC -ts recent; firewall-cmd --list-all

6. What changed recently?

dnf history | head -5; ausearch -k priv -ts today | tail -3

14. Lab 1: Build and secure orders01 end to end

Why do we need this?

On a fresh Rocky 9 VM, follow sections 1 to 5 and finish with all security checks passing.

What is it?

A full hands-on lab. Run every step on a test Linux machine (an EC2 instance, a VM, or WSL).

How to do it (step by step)

1. Write PLAN.md and record facts.

wc -l /root/PLAN.md; hostname

Output:

24 /root/PLAN.md
orders01.shree.local

2. Users, sudo and LVM.

getent group admins; findmnt -no SOURCE /srv/app

Output:

admins:x:1001:ravi,asha
/dev/mapper/vg_data-lv_app

3. App and nginx.

curl -s localhost/; systemctl is-enabled orders nginx

Output:

Shree Traders orders
enabled
enabled

4. SSH and firewall hardening.

sshd -T | grep -c -E 'permitrootlogin no|passwordauthentication no'; firewall-cmd --list-services

Output:

2
dhcpv6-client http https

5. Updates, fail2ban, audit, TLS.

systemctl is-active dnf-automatic.timer fail2ban auditd; curl -sk https://localhost/health

Output:

active
active
active
ok

15. Lab 2: Monitor, back up, break and fix

Why do we need this?

Add monitoring and backups, then have a partner run all six break scenarios; fix each within 10 minutes and log it.

What is it?

A full hands-on lab. Run every step on a test Linux machine (an EC2 instance, a VM, or WSL).

How to do it (step by step)

1. Health timer and alert test.

systemctl stop orders; sleep 65; journalctl -t healthcheck -n1 -o cat; systemctl start orders

Output:

ALERT app health failed;

2. Backup and restore test.

restic snapshots --compact | tail -1; restic restore latest --target /tmp/r -q && ls /tmp/r/srv/app

Output:

1 snapshots
app.py

3. Partner breaks: SELinux boolean off.

curl -sI localhost | head -1; getsebool httpd_can_network_connect

Output:

HTTP/1.1 502 Bad Gateway
httpd_can_network_connect --> off

4. Fix and verify.

setsebool -P httpd_can_network_connect on; curl -sI localhost | head -1

Output:

HTTP/1.1 200 OK

5. Partner breaks: fills the disk. Fix and log.

truncate -s 0 /srv/app/debug.log; df --output=pcent /srv/app | tail -1; echo '2026-10-26 12:30 disk full, truncated debug.log, added logrotate' >> /root/INCIDENTS.log

Output:

  2%

6. Final checklist after reboot.

bash check.sh | grep -c PASS

Output:

10

16. Frequently asked questions

17. Interview questions and answers

Beginner level

Mid level level

Senior level

18. Related chapters

• Linux Ops Refresh for DevOps
• Bash Scripting for Automation
• Linux grep and find Commands with Examples
• How to Set Up Passwordless SSH Between Linux Servers

Revision, comparison and interview cards

Revise this lesson in a few minutes. Save the cards on your phone or download them as PNG files. The QR code on each card opens this lesson.

More cards: Ravi Sir's Cards.
