Chapter 18: Kubernetes Workloads

18.12 The Service spreads traffic across ready Pods

By Ravindra Bagale · Last updated: 25 October 2026

Why: the problem

Pods come and go. Every new Pod gets a new IP. If the Myntra cart service talked to the pricing service by Pod IP, it would break on every deploy. A Service fixes this. It gives a group of Pods one stable virtual IP and one DNS name, like pricing. It watches which Pods match its label selector and are ready, and sends each connection to one of them. Pods that fail their readiness probe are removed from the list until they recover. So the Service is also a simple load balancer and a safety net. In this lesson you will put a Service in front of three Pods that print their own name, prove that traffic spreads, make one Pod unready and see it leave the list, and look at the EndpointSlice that holds the real Pod IPs.

What we will build

You will run three http-echo Pods that answer with their Pod name, a ClusterIP Service called who, and a client loop that counts answers. Then you will break readiness on one Pod, scale up, and expose the Service on your laptop with port-forward and NodePort.

What: every term in plain English

• Service — A stable virtual IP and DNS name for a set of Pods.
• ClusterIP — The default Service type. Reachable only inside the cluster.
• NodePort — Opens the same port (30000-32767) on every node.
• Selector — The labels a Service uses to find Pods.
• EndpointSlice — The list of ready Pod IPs behind a Service.
• kube-proxy — The agent on each node that programs iptables or IPVS rules for Services.
• Readiness — A Pod is added to the Service only when it is ready.
• port and targetPort — The Service port clients use, and the container port it forwards to.

How: step by step

1. Start a lab cluster

   kind create cluster --name lab
   kubectl get nodes


   What it does: Creates a one-node Kubernetes cluster inside Docker. On minikube use: minikube start.

   Output

   Creating cluster "lab" ...
    ✓ Ensuring node image (kindest/node:v1.30.0)
    ✓ Preparing nodes
   Set kubectl context to "kind-lab"
   NAME                STATUS   ROLES           AGE   VERSION
   lab-control-plane   Ready    control-plane   40s   v1.30.0


2. Make a practice namespace

   kubectl create namespace practice
   kubectl config set-context --current --namespace=practice


   What it does: Keeps all lab objects in one folder that is easy to delete.

   Output

   namespace/practice created
   Context "kind-lab" modified.


3. Deploy three Pods that say their name

   kubectl apply -f who.yaml


   What it does: The file is in Example 1.

   Output

   deployment.apps/who created
   service/who created


4. See the Service

   kubectl get svc who


   What it does: A stable ClusterIP.

   Output

   NAME   TYPE        CLUSTER-IP     EXTERNAL-IP   PORT(S)
   who    ClusterIP   10.96.81.200   none          80/TCP


5. See the endpoints

   kubectl get endpointslice -l kubernetes.io/service-name=who


   What it does: The real Pod IPs.

   Output

   NAME        ADDRESSTYPE   PORTS   ENDPOINTS
   who-8x2kq   IPv4          5678    10.244.0.11,10.244.0.12,10.244.0.13


6. Call it by DNS

   kubectl run c --rm -it --image=busybox:1.36 --restart=Never -- wget -qO- who


   What it does: Any Pod can use the name.

   Output

   who-6b9f7c8d5-4kx2m


7. Port-forward to your laptop

   kubectl port-forward svc/who 8080:80


   What it does: Your laptop port 8080 goes to the Service. Ctrl+C to stop.

   Output

   Forwarding from 127.0.0.1:8080 -> 5678


Example 1: Three Pods and a ClusterIP Service

Stack. kind, Kubernetes 1.30

Goal. Three Pods and a ClusterIP Service.

who.yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: who
spec:
  replicas: 3
  selector:
    matchLabels: {app: who}
  template:
    metadata:
      labels: {app: who}
    spec:
      containers:
      - name: echo
        image: hashicorp/http-echo:1.0
        args: ["-text=$(POD_NAME)"]
        env:
        - name: POD_NAME
          valueFrom:
            fieldRef: {fieldPath: metadata.name}
        ports: [{containerPort: 5678}]
        readinessProbe:
          httpGet: {path: /, port: 5678}
          periodSeconds: 3
---
apiVersion: v1
kind: Service
metadata:
  name: who
spec:
  selector: {app: who}
  ports:
  - port: 80
    targetPort: 5678

What each line does

• fieldRef metadata.name — Puts the Pod name into an env var.
• -text=$(POD_NAME) — Each Pod answers with its own name.
• readinessProbe — Decides if the Pod is in the Service.
• selector app: who — Matches the three Pods.
• port 80 targetPort 5678 — Clients use 80; Pods listen on 5678.

Green output

deployment.apps/who created
service/who created
NAME   READY   UP-TO-DATE   AVAILABLE
who    3/3     3            3

Expected result. The Service name who now works from any Pod in the namespace, and as who.practice.svc.cluster.local from others.

Example 2: Prove traffic is spread

Stack. kube-proxy iptables mode

Goal. Prove traffic is spread.

terminal

kubectl run load --image=busybox:1.36 --restart=Never -- sh -c 'for i in $(seq 300); do wget -qO- who; done'
kubectl wait --for=jsonpath='{.status.phase}'=Succeeded pod/load --timeout=60s
kubectl logs load | sort | uniq -c

What each line does

• seq 300 — 300 requests.
• wget -qO- who — Each request opens a new connection, so kube-proxy may pick a new Pod.
• sort | uniq -c — Counts answers per Pod.

Green output

 97 who-6b9f7c8d5-4kx2m
104 who-6b9f7c8d5-9tqz7
 99 who-6b9f7c8d5-m2vn8

Expected result. Roughly a third each. In iptables mode the choice is random per connection, which evens out.

Example 3: An unready Pod leaves the Service

Stack. EndpointSlice API

Goal. An unready Pod leaves the Service.

terminal

BAD=$(kubectl get pod -l app=who -o name | head -1)
kubectl label $BAD app=who-off --overwrite
kubectl get endpointslice -l kubernetes.io/service-name=who
kubectl get pods -L app
kubectl scale deploy who --replicas=5
kubectl get endpointslice -l kubernetes.io/service-name=who

What each line does

• label app=who-off — The Pod no longer matches the selector. The same happens when readiness fails.
• endpointslice — Now lists only matching, ready Pods.
• New Pod — The Deployment also makes a replacement.
• scale to 5 — New Pods join the slice as soon as they are ready.

Green output

pod/who-6b9f7c8d5-4kx2m labeled
NAME        ADDRESSTYPE   PORTS   ENDPOINTS
who-8x2kq   IPv4          5678    10.244.0.12,10.244.0.13,10.244.0.14
NAME                  READY   STATUS    APP
who-6b9f7c8d5-4kx2m   1/1     Running   who-off
who-6b9f7c8d5-9tqz7   1/1     Running   who
who-6b9f7c8d5-m2vn8   1/1     Running   who
who-6b9f7c8d5-x7k2p   1/1     Running   who
deployment.apps/who scaled
who-8x2kq   IPv4          5678    10.244.0.12,10.244.0.13,10.244.0.14,10.244.0.15,10.244.0.16

Expected result. The Service list follows labels and readiness in seconds. You never edit IPs by hand.

Verify: did it work?

1. Check the Service has endpoints

   kubectl describe svc who | grep -E "Selector|Endpoints"


   What it does: Empty Endpoints means no Pod matches or none is ready.

   Output

   Selector:          app=who
   Endpoints:         10.244.0.12:5678,10.244.0.13:5678,10.244.0.14:5678 + 2 more...


2. Try NodePort

   kubectl patch svc who -p '{"spec":{"type":"NodePort"}}' && kubectl get svc who && docker exec lab-control-plane curl -s localhost:$(kubectl get svc who -o jsonpath={.spec.ports[0].nodePort})


   What it does: Opens a port on the node. Lesson 19 covers all Service types.

   Output

   NAME   TYPE       CLUSTER-IP     PORT(S)
   who    NodePort   10.96.81.200   80:31544/TCP
   who-6b9f7c8d5-9tqz7


When it is red 1

Service has no endpoints (Endpoints: none)

Cause. The selector does not match the Pod labels, or no Pod is ready.

Fix, step by step

1. Compare kubectl get svc who -o yaml selector with kubectl get pods --show-labels.
2. Check readiness with kubectl describe pod.

When it is red 2

wget: can't connect to remote host (10.96.81.200): Connection refused

Cause. targetPort does not match the port the container listens on.

Fix, step by step

1. Check the containerPort and the app listen port.
2. Fix targetPort.

When it is red 3

wget: bad address 'who'

Cause. DNS lookup failed: wrong namespace or CoreDNS is down.

Fix, step by step

1. Use who.practice.svc.cluster.local.
2. Run kubectl get pods -n kube-system -l k8s-app=kube-dns.

Cleanup

1. Delete the lesson objects

   kubectl delete deploy who
   kubectl delete svc who
   kubectl delete pod load --ignore-not-found
   kubectl delete pod -l app=who-off


   What it does: Removes the Deployment, Service and leftover Pods.

   Output

   deployment.apps "who" deleted
   service "who" deleted


2. Delete the practice namespace

   kubectl delete namespace practice


   What it does: Deletes every object you made in this lesson in one go.

   Output

   namespace "practice" deleted


Practice tasks

Homework: try at home

Recap

• A Service gives Pods a stable IP and DNS name.
• It sends traffic only to ready Pods that match its selector.
• EndpointSlices hold the real Pod IPs.
• kube-proxy spreads connections across them.
• port-forward and NodePort reach it from outside.

FAQ

Is a Service a real process?

No. ClusterIP is virtual; kube-proxy rules on each node do the forwarding.

Does a Service retry a failed request?

No. Retries are the client or a service mesh job.

Why did one long connection always hit one Pod?

Balancing is per connection, not per request. HTTP keep-alive reuses one connection.

Endpoints or EndpointSlice?

EndpointSlice is the newer, scalable API. Endpoints still exists for older tools.

What is a headless Service?

clusterIP: None. DNS returns Pod IPs directly; used with StatefulSets.

Interview questions

1. How does a Service load balance?

   kube-proxy programs iptables or IPVS rules so each new connection to the ClusterIP goes to one ready endpoint.

2. What happens when a Pod fails readiness?

   It is removed from the EndpointSlice and gets no new traffic until ready again.

3. Service has no endpoints. What do you check?

   Selector versus Pod labels, readiness, and targetPort.

4. How does DNS work for Services?

   CoreDNS returns the ClusterIP for NAME.NAMESPACE.svc.cluster.local.

5. Why not use Pod IPs directly?

   Pod IPs change on every restart and scale event.
